1400 Security Appliances

Small and remote branch offices need the same protections from sophisticated cyber attacks and zero-day threats as main corporate offices. The Check Point 1400 appliances are ideal for small and branch office deployments, delivering all-in-one advanced threat prevention with SandBlast Zero-Day Protection (sandboxing), flexible network connectivity, and maximum port density—all in a compact, high-performance desktop form factor.

Benefits

Big security in a compact footprint

  • Fully integrated next-generation threat prevention including: firewall, IPS, IPsec VPN, application control, anti-spam, antivirus, anti-bot, URL filtering, email security, and user awareness
  • Continuous security updates from Check Point ThreatCloud™
  • Compact and quiet desktop form factor

Easy to deploy, centrally managed

  • Rapid deployment via an intuitive, web-based management interface and pre-defined security policies
  • Large scale, profile-based central management for maintaining hundreds of devices

Extensible security tailored for small and branch offices

  • Optimized to deliver up to 550 Mbps of threat prevention throughput
  • Flexible Internet access options include 1GbE copper or fiber ports and support for external 3G/4G/LTE wireless modems
  • Up to 18 1GbE ports and 802.11ac Wi-Fi connectivity

Features

All-inclusive threat prevention security without compromise

Branch offices are ripe targets for cyber criminals looking for unrestricted access to corporate networks: the fact that they are smaller offices doesn’t mean they are smaller targets. This is why the Check Point 1400 appliances are based on the same industry-leading threat prevention technology that is used to secure Fortune 100 organizations, optimized on an enterprise-grade chassis for maximum performance.

Comprehensive security protections include firewall, VPN, IPS, antivirus, anti-bot, application visibility and control, URL filtering, email security and SandBlast Zero-Day Protection (sandboxing)—all in a quiet, compact desktop form factor. What’s more, the 1400 appliances receive continuous updates from Check Point ThreatCloud™, providing maximum protection against the latest threats and malicious activity.


Inspect Encrypted Connections

There is a shift towards more use of HTTPS, SSL and TLS encryption to increase Internet security. At the same time files delivered into the organization over SSL and TLS represent a stealthy attack vector that bypasses traditional security implementations. Check Point Threat Prevention looks inside encrypted SSL and TLS tunnels to detect threats, ensuring users remain in compliance with company policies while surfing the Internet and using corporate data.


Local and central management options

The Check Point 1400 appliances are as easy to manage as they are to deploy, whether you have technical staff on hand or not. The intuitive, web-based management interface allows for comprehensive on-site management and reporting of all security activity. Branch deployments can also be centrally managed with Check Point enterprise security management or multi-domain management products, enabling organizations to define a consistent security policy and device profile for thousands of 1400 appliances.

Rapid setup and configuration

Bringing advanced threat prevention security to every business location has traditionally been prohibitive due to a lack of dedicated IT staff and resources at branch offices. The Check Point 1400 appliances are designed to be easy to deploy and use—even for non-technical staff. Initial setup is performed through an easy-to-use management interface, and configuration is a snap with a simple yet powerful start-up wizard, allowing the 1400 appliances to be deployed in minutes.


Flexible connectivity, high port density

The 1400 appliances are built to accommodate maximum flexibility for greater productivity in today’s enterprise branch offices. Flexible connectivity options include:

  • Up to 18 1Gbps Ethernet ports
  • USB 3.0 ports supporting external 3G/4G/LTE modems for additional WAN connectivity and redundancy
  • Integrated 802.11ac Wi-Fi supporting WPA and WPA2 authentication as well as secure guest access


Learn More

Specifications

Appliance Model

1430

1450

1470

1490

Ideal Testing Conditions 1
Firewall, 1518 byte UDP (Mbps)

2,000

2,500

3,200

4,000

IPS Throughput (Mbps)

325

575

700

800

NGFW Throughput (Mbps)1

300

490

625

800

Threat Prevention (Mbps)2

225

400

500

550

VPN AES-128 Throughput (Mbps)

275

500

500

1000

Connections per Second

20,000

27,000

30,000

40,000

Concurrent Connections

500,000

500,000

500,000

500,000

Real-World Production Conditions
SecurityPower

75

141

194

233

Firewall Throughput (Mbps)

900

1,100

1,600

1,800

IPS Throughput (Mbps)

175

225

285

375

NGFW Throughput (Mbps)1

100

210

240

310

Threat Prevention (Mbps)2

90

150

175

220

Your performance may vary depending on different factors. Contact a Check Point Partner to find an appliance that matches your unique requirements.
1 Includes Firewall, Application Control and IPS Software Blades.
2 Includes Firewall, Application Control, URL Filtering, IPS, Antivirus, Anti-Bot and SandBlast Zero-Day Protection.
Appliance

1430

1450

1470

1490

Networking
WAN

1X 1 GbE Copper

1X 1 GbE Copper

DMZ

1X 1 GbE Copper

1X 1 GbE Copper

LAN

6x 1GbE

16x 1GbE

Power Over Ethernet (Optional)

4x 1GbE Out of the 16 LAN Ports

Wi-Fi (Optional)

802.11 b/g/n/ac MIMO 3x3

802.11 b/g/n and 802.11 n/ac MIMO

Radio Band

2.4GHz or 5GHz

2 Concurrent
2.4Ghz and 5Ghz

Additional Features
PoE/PoE+ (Optional)

USB Ports

1

2

SD Card Slot

1 (Micro SDHC)

1 (Micro SDHC)

3G/4G Modem Support

Yes, See sk92809

Yes, See sk92809

Physical
Mounting

Desktop and Rack

Desktop and Rack

AC

100-240V, 50 - 60 Hz

Dimensions (WxHxD)

210 x 42.5 x 155 mm

210 x 42.5 x 200.5 mm

Weight

1.3 kg

1.6 kg

Operating Environment

0° to 40°C

0° to 40°C

Software Blade

NGTP

NGTX

Firewall

Identity Awareness

IPSec VPN

Advanced Networking & Clustering

Mobile Access1

IPS

Application Control

URL Filtering

Antivirus

Anti-Spam & Email Security

Anti-Bot

SandBlast Threat Emulation

*

NGTP = Next Generation Threat Prevention
NGTX = NGTP plus SandBlast
✔ - Included
* - Optional
1 SSL VPN Portal is not supported
